2k wired doorbell use mechanical chime

[macman71]

New here, just started with the eufy eco system coming from an Arlo video solution. Here is my situation i do want my mechanical 3 bell chime to play when the button is pressed. At this moment it does not work for the front door however my side and rear door will use the mechanical chime no issues. My doorbell chime is old from the 60’s maybe 70’s love it. Its made by nutone I had to change the original nutone transformer that was 15VA 15V to a modern that did 30VA and the required voltage. eufy device works well no issues on power, it passed the voltage test and it’s working. My chime is not like what you see in all of the YT videos or even the manual for eufy that show a Front, Trans, Rear. It has a COM TRANS FRONT REAR SIDE, and EXT FRONT. Because its old. From what I understand is that the video doorbell will close the circuit so the mechanical chime will sound but that is not what is happening. I don need to bypass the chime to provide enough power because is getting enough power. I am not sure what else to try to get it to work. I attached the connections on the chime to give a better reference.

Thanks

[ele1980]

1st I’m a electrician just so you know. Looking at your picture some of the wires on the chime don’t look like they are making good connections but they might still be working but could use some attention just remove 1 wire at a time and reconnect making sure they are completely around the screw terminal and loops in a clockwise direction so the wire doesn’t back off when tightening. So with that said I assume you’re new Eufy door bell is a wired unit (what model?) mine works the house chime perfectly and I didn’t have to modify any of the wiring do you realize that you have to turn the option of using house chime on in the app? At least that’s how my DB camera is I’ll try to post a screenshot. If this doesn’t work message me and maybe I can be of further assistance I leave for work shortly so I might not be answer till later today
